Citizen CL-S700 Label Maker User Manual



Chapter 5 Parts Lists
CL-S700/CL-S703 5-44
PARTS LIST for CL-S700/CL-S703 TITLE: SA, Ope-pane Sheet No. 1/1
Drawing No. 11 Rev. No. 0
Location Part Name Part No.
Q'ty/
Unit
Remarks @
11-1 Sheet, Ope-Pane JN54901-0 1
11-2 Cover, Ope-Pane JN56202-0 1
11-3 SA, Cover Open Sens JN68705-0 1
11-4 SA, Ope-Pane PCB JN66704-0 1
11-5 SA, Ope-Pane Plate JN56706-0 1
11-6 Switch, Pause JN56212-0 1
11-7 Switch, Feed JN56211-0 1
11-8 Switch, Menu JN56210-0 1
11-9 Switch, Stop JN56213-0 1
11-10 Cover, LCD JN54102-0 1
11-11 Screw, PHT (#2), M3.0x6 E10130-060F 4
11-12 Screw, BH, M3.0x5 E00530-050F 2
