CY7C67300
Document #: 38-08015 Rev. *J Page 69 of 99
Receive Interrupt Flag (Bit 2)
The Receive Interrupt Flag is a read only bit that indicates if a
byte mode receive interrupt triggered.
1: Indicates a byte mode receive interrupt triggered
0: Indicates a byte mode receive interrupt did not trigger
Transmit Interrupt Flag (Bit 1)
The Transmit Interrupt Flag is a read only bit that indicates a byte
mode transmit interrupt triggered.
1: Indicates a byte mode transmit interrupt triggered
0: Indicates a byte mode transmit interrupt did not trigger
Transfer Interrupt Flag (Bit 0)
The Transfer Interrupt Flag is a read only bit that indicates a
block mode interrupt triggered.
1: Indicates a block mode interrupt triggered
0: Indicates a block mode interrupt did not trigger
SPI Interrupt Clear Register [0xC0D0] [W]
Register Description
The SPI Interrupt Clear register is a write only register that allows
the SPI Transmit and SPI Transfer Interrupts to be cleared.
Transmit Interrupt Clear (Bit 1)
The Transmit Interrupt Clear bit is a write only bit that clears the
byte mode transmit interrupt. This bit is self clearing.
1: Clear the byte mode transmit interrupt
0: No function
Transfer Interrupt Clear (Bit 0)
The Transfer Interrupt Clear bit is a write only bit that clears the
block mode interrupt. This bit is self clearing.
1: Clear the block mode interrupt
0: No function
Reserved
Write all reserved bits with ’0’.
SPI CRC Control Register [0xC0D2] [R/W]
Register Description
The SPI CRC Control register provides control over the CRC
source and polynomial value.
CRC Mode (Bits [15:14)
The CRCMode field selects the CRC polynomial as defined in
Table 112 on page 70.
Table 110. SPI Interrupt Clear Register
Bit # 15 14 13 12 11 10 9 8
Field Reserved
Read/Write - - - - - - - -
Default 0 0 0 0 0 0 0 0
Bit # 7 6 5 4 3 2 1 0
Field
Reserved Transmit
Interrupt
Clear
Transfer
Interrupt
Clear
Read/Write - - - - - - W W
Default 0 0 0 0 0 0 0 0
Table 111. SPI CRC Control Register
Bit # 15 14 13 12 11 10 9 8
Field
CRC Mode CRC
Enable
CRC
Clear
Receive
CRC
One in
CRC
Zero in
CRC
Reserved...
Read/Write R/W R/W R/W R/W R/W R R -
Default 0 0 0 0 0 0 0 0
Bit # 7 6 5 4 3 2 1 0
Field ...Reserved
Read/Write - - - - - - - -
Default 0 0 0 0 0 0 0 0
