EPSON Stylus PHOTO RX600/610, RX620/630 Revision C
Adjustment Adjustments by Adjustment Program 74
5.2.3 Maintenance
This section describes the maintenance items of the adjustment program.
5.2.3.1 Head cleaning
You can execute more intensive cleaning than Head Cleaning, which is carried out by
selecting it in the menu on the Operation Panel. This function releases the Head Nozzle
from clogging which can cause dot missing.
Ink consumption (every cleaning)
5.2.3.2 Ink charge
When the Head or Printer Mechanism has been replaced, ink is not available in the ink
route just after its installation, thus ink needs to be filled.
When the following work has been performed, ink must be initially filled by executing
this item.
Printer Mechanism replacement
Printer Head replacement
Ink consumption (every charging)
Figure 5-13. Head Cleaning Screen
Figure 5-14. Ink Charging Screen
Type of Cartridge
Model Number
Consumption
Europe, EAI Asia/Latin
Black I/C T0481 T0491
7%
Color I/C
T0482, T0483, T0484,
T0485, T0486
T0492, T0493, T0494,
T0495, T0496
C H E C K
P O I N T
If the nozzle is not released from clogging even by this cleaning,
execute initial ink filling.
(Refer to “Ink charge” (p74))
Type of Cartridge
Model Number
Consumption
Europe, EAI Asia/Latin
Black I/C T0481 T0491
15%
Color I/C
T0482, T0483, T0484,
T0485, T0486
T0492, T0493, T0494,
T0495, T0496
