4-15
IPL T S Series • Communication and Control
Command ASCII (Telnet)
(host to unit)
URL Encoded (Web)
(host to unit)
Response
(unit to host)
Additional description
Remap port designations
For security reasons the network administrator may wish to assign new/different port numbers to the controller’s Telnet, Web browser, and direct access ports or to disable one
or more ports. Typically Telnet uses port 23, Web access is via port 80 (HTTP), and direct access is via port 2001.
C
Do not set two or more ports to the same port number. Setting two ports to the same number could cause networking conflicts and will also result in an E13 (invalid
parameter) error.
N
If you remap a port, you must set the port number to 1024 or higher, unless you reset the port to the default number or disable the port by setting it to 0.
Set Telnet port map
24
E
{port#}MT
}
W{port#}MT
|
Pmt{port#}
]
Select a number for the port that will not
conflict with any other ports.
Reset Telnet port
map
24
E
23MT
}
W23MT
|
Pmt00023
]
This resets the Telnet port to port 23.
Disable Telnet port
24
E
0MT
}
W0MT
|
Pmt00000
]
Setting the port number to 0 disables the
port.
View Telnet port map
E
MT
}
WMT
|
{port#}
]
Set Web port map
24
E
{port#}MH
}
W{port#MH
|
Pmh{port#}
]
Reset Web port map
24
E
80MH
}
W80MH
|
Pmh00080
]
This resets the Web port to port 80.
Disable Web port
24
E
0MH
}
W0MH
|
Pmh00000
]
View Web port map
24
E
MH
}
WMH
|
{port#}
]
Set Direct Access port
map
24
E
{port#}MD
}
W{port#}MD
|
Pmd{port#}
]
Reset Direct Access
port map
24
E
2001MD
}
W2001MD
|
Pmd02001
]
This resets the direct access port to port
2001.
Disable Direct Access
port
24
E
0MD
}
W0MD
|
Pmd00000
]
View Direct Access
port map
E
MD
}
WMD
|
{port#}
]
N
Duplicate port# assignments are not permitted (for example, Telnet and Web cannot be the same) and result in an E13 (invalid parameter) response.
