Configuration Options
C-2
3162-A2-GB20-40August 2000
Network Interface Configuration Options
Table C-1. Network Interface Configuration Options (1 of 2)
Line Framing Format: ESF (Factory 1) D4 (Factory 2)
D4 ESF
The framing format to be used on the network interface.
D4 – Configures for the D4 framing format.
ESF – Configures for the Extended Superframe format.
Line Coding Format: B8ZS (Factory 1) AMI (Factory 2)
AMI B8ZS
The line coding format to be used on the network interface.
AMI – Configures for the Alternate Mark Inversion coding format.
B8ZS – Configures for the Bipolar 8 Zero Suppression coding format.
Bit Stuffing: 62411
62411 Disable
Determines when bit stuffing is performed to meet the ones density requirements for
data transmission on the network.
62411 – Specifies that a one be inserted in the data stream after 15 consecutive zeros
or when the density of ones falls below 12.5% (complies with AT&T TR 62411).
Disable – Disables bit stuffing so that ones density is not enforced.
NOTES: – To comply with Canadian DOC CS-03 regulations, equipment installed
in Canada must be configured to select 62411.
– This configuration option is only available if the network interface line
coding format is set to AMI.
Line Build Out (LBO): 0.0
0.0 –7.5 –15 –22.5
The line build out (LBO), in decibels, for the signal transmitted to the network.
Management Link: Disable
Enable Disable
Specifies whether Facility Data Link (FDL) is enabled. Selecting Enable allows SNMP or
Telnet traffic to flow over the
4 kbps data link provided by FDL. Running SNMP or Telnet over FDL requires an
end-to-end FDL connection and cannot be terminated within the network.
Enable – Enables the FDL management link for SNMP or Telnet.
Disable – Disables the FDL management link.
NOTES: – This configuration option is only available if the framing format is set to
ESF.
– This configuration option is not available if EDL is enabled.
– If the local DSU/CSU’s FDL is enabled, the remote DSU/CSU’s FDL
must also be enabled.
