Pin Assignments
D-12
3162-A2-GB20-40August 2000
Table D-6. V.35 Cable Interface
Signal
CCITT
Number
Direction Pin
Shield — — A
Signal Common 102 — B
Transmitted Data 103 To DSU/CSU P (A)
S (B)
Received Data 104 From DSU/CSU R (A)
T (B)
Request to Send 105 To DSU/CSU C
Clear to Send 106 From DSU/CSU D
Data Channel Received
Line Signal Detector
109 From DSU/CSU F
Data Set Ready 107 From DSU/CSU E
Data Terminal Ready 108/1, /2 To DSU/CSU H
Transmit Signal Element
Timing (DTE Source)
113 To DSU/CSU U (A)
W (B)
Transmit Signal Element
Timing (DCE Source)
114 From DSU/CSU Y (A)
AA (B)
Receiver Signal Element
Timing (DCE Source)
115 From DSU/CSU V (A)
X (B)
Local Loopback 141 To DSU/CSU L
Loopback/Maintenance 140 To DSU/CSU N
Test Indicator 142 From DSU/CSU NN
