Physical Description
The DSU/CSU front panel (Figure 1-1) contains twelve light-emitting diodes
(LEDs) and six test jacks.
The LEDs are described in Front Panel LEDs in Chapter 3, Operation.
The test jacks are described in Test Jacks in Chapter 5, Monitoring and Testing.
The DSU/CSU rear panel (Figure 1-2) contains the connectors required for the
operation of the DSU/CSU. The connectors and their functions are listed in
Table 1-1.
F1 F2 F3
OK
FAIL TEST SIG OOF ALRM
NETWORK RXD
EER SIG ALRM PDVOOF BPV
3162
ACCULINK
In
Out
In
Out
In
Out
NET
MON EQPT
DTR TXD CTS RTS
496-15001
Figure 1-1. 3162 DSU/CSU Front Panel
00-16852
POWER
PORT 2
PORT 1
10 BASE-T
COM DSX-1MODEM
EXT CLK
NETWORK
Figure 1-2. 3162 DSU/CSU Rear Panel
