Configuring the 10BaseT Port
To configure the 10BaseT port for SNMP access:
H Set the Port Use configuration option to your network protocol.
H Set the 10BaseT port’s IP address and subnet mask.
H Set the default gateway address.
" Procedure
To configure the 10BaseT port:
1. From the Main Menu screen, select Configuration.
2. From the Load Configuration From screen, select Current.
3. From the Configuration Edit/Display screen, select User Interface.
4. From the User Interface screen, select Ethernet Port.
The Ethernet Port Options screen appears.
5. In the Port Use field, select 802.3 or Version 2.
6. Enter the IP Address, Subnet Mask, and Default Gateway Address.
7. When you are through making configuration option changes, select S
ave to
store these changes in nonvolatile memory. If you want to return to the User
Interface screen, press your Esc key and then save your changes from that
screen.
main/config/user/ethernet
Customer ID: Node A Model: 3162
ETHERNET PORT OPTIONS
Port Use: Version 2
IP Address: 000.000.000.000 Clear
Subnet Mask: 000
.000.000.000 Clear
Default Gateway Address: 000
.000.000.000 Clear
–––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Ctrl-a to access these functions, ESC for previous menu M
ainMenu Exit
S
ave
Figure 4-2. Ethernet Port Options Screen
