Operator Status Row Indicators
The operator status row is the area below the last data row and is separated from the rest
of the screen by one nonintensified line. The operator status row contains symbols that
indicate current operating conditions. These symbols are either System indicators or
Local indicators.
Note: The symbols shown below are generated when the display station is attached to
a MTX/MTC 1174 Network Controller, a Memorex Telex 1274 Control Unit, a
Memorex Telex 1374 Control Unit, an IBM 3274 Control Unit, or an IBM 3174
Control Unit.
Figure 3-17. System Operator Status Row Fields
System Symbols
The following types of operator status row symbols are generated by the system:
Readiness and System Connection
“Do Not Enter” (Input Inhibited)
Reminder
Shift and Mode
Printer Status*
Entry Assist
Response Time Indicators
* Printer Status symbols are system symbols if the printer is a host addressable printer.
They are local symbols if the printer is a local printer.
Readiness
and System
Connection
Input
Inhibited
Reminders
Shift and
Modes
Printer
Status
Record/
Playback
Entry Assist/
Device
Dependent
Symbols
Column Numbers
0 – 8 9 – 17 21 – 30 25 – 27 36 – 45 53 – 56 54 – 74 66 – 80
Local Error
