Reference Manual for the 54 Mbps Wireless ADSL Firewall Router DG834G
Managing Your Network 6-5
202-10006-01
Table 6-1. Menu 3.2 - Router Status Fields
Field Description
Account Name The Host Name assigned to the router in the Basic Settings menu.
Firmware Version This field displays the router firmware version.
ADSL Port These parameters apply to the Internet (ADSL) port of the router.
MAC Address This field displays the Ethernet MAC address being used by the Internet
(ADSL) port of the router.
IP Address This field displays the IP address being used by the Internet (ADSL) port
of the router. If no address is shown, the router cannot connect to the
Internet.
DHCP If None, the router will use a fixed IP address on the ADSL.
If Client, the router will obtain an IP address dynamically from the ISP
IP Subnet Mask This field displays the IP Subnet Mask being used by the Internet
(ADSL) port of the router.
Domain Name Server (DNS) This field displays the DNS Server IP addresses being used by the
router. These addresses are usually obtained dynamically from the ISP.
LAN Port These parameters apply to the Local (ADSL) port of the router.
MAC Address This field displays the Ethernet MAC address being used by the Local
(LAN) port of the router.
IP Address This field displays the IP address being used by the Local (LAN) port of
the router. The default is 192.168.0.1
DHCP If OFF, the router will not assign IP addresses to computers on the LAN.
If ON, the router will assign IP addresses to computers on the LAN.
IP Subnet Mask This field displays the IP Subnet Mask being used by the Local (LAN)
port of the router. The default is 255.255.255.0.
Modem These parameters apply to the Local (WAN) port of the router.
ADSL Firmware Version The version of the firmware.
Modem Status The connection status of the modem.
Downstream Speed The speed at which the modem is receiving data from the ADSL line.
Upstream Speed The speed at which the modem is transmitting data to the ADSL line.
VPI The Virtual Path Identifier setting.
VCI The Virtual Channel Identifier setting.
