Reference Manual for the 54 Mbps Wireless ADSL Firewall Router DG834G
6-6 Managing Your Network
202-10006-01
Click the Show Statistics button to display router usage statistics, as shown in Figure 6-3 below:
Figure 6-4: Router Statistics screen
This screen shows the following statistics:
Wireless Port These parameters apply to the wireless port of the router
Name (SSID) Wireless network name or Service Set Identifier
Region The region in which the wireless device is operating
Channel The operating frequency that is being used.
Wireless AP Displays whether wireless access points can connect.
Broadcast Name If enabled, the SSID is broadcast to all wireless stations.
Table 6-1. Menu 3.2 - Router Status Fields
Field Description
