Reference Manual for the 54 Mbps Wireless ADSL Firewall Router DG834G
Managing Your Network 6-11
202-10006-01
Log entries are described in Table 6-1 below:
Log action buttons are described in Table 6-2 below:
Selecting What Information to Log
Besides the standard information listed above, you can choose to log additional information. Those
optional selections are as follows:
• Attempted access to blocked site
• Connections to the Web-based interface of the router
• Router operation (start up, get time, etc.)
• Known DoS attacks and Port Scans
Table 6-1. Security Log entry descriptions
Field Description
Date and Time The date and time the log entry was recorded.
Description or Action The type of event and what action was taken if any.
Source IP The IP address of the initiating device for this log entry.
Source port and
interface
The service port number of the initiating device, and whether
it originated from the LAN or WAN
Destination The name or IP address of the destination device or Web site.
Destination port and
interface
The service port number of the destination device, and
whether it is on the LAN or WAN.
Table 6-2. Security Log action buttons
Field Description
Refresh Refresh the log screen.
Clear Log Clear the log entries.
Send Log Email the log immediately.
Apply Apply the current settings.
Cancel Clear the current settings.
