5. PROGRAMMING OPERATIONS
EO1-11138
5-13
Major-Minor Grouping Method Example:
(In this case, you should check the logical linkage between the Major Groups and Minor
Groups.)
Major GP 01 Major GP 02
Minor Minor Minor Minor Minor
GP01 GP02 GP03 GP04 GP05
DP01 DP02 DP04 DP06 DP07 DP10 DP11 DP14 DP16
0101 0101 0102 0103 0103 0204 0204 0205 0205
Linked Group Code in setting
“A” Grouping and “B” Grouping Method Example:
(In this case, you may think that each department data are processed into max. 2 different
types of groupings.)
A-GP A-GP A-GP B-GP B-GP B-GP
01 02 03 01 02 03
DP01 DP02 DP04 DP06 DP07 DP10 DP11 DP14 DP16 DP17
0100 0100 0201 0301 0300 0302 0002 0003 0003 0002
Linked Group Code in setting
2 Department Name
Enter a maximum of 16 regular-sized or 8 double-sized characters. See the section 5.2
Character Entries. End with [ST].
When no name is programmed for a department, the following will be the auto-program name
(initial setting) for printing:
D P
xx
Department Code 01 to 99
double-sized characters
Address No. Description of Programming Contents
-- Continued --
-- Continued on next page --
