5. PROGRAMMING OPERATIONS
EO1-11138
5-36
5.4 How to Access a Program Item
*
SET
*
02-06-1999 12:34
PROGRAMMING PLU KEY S1
01
02
03
04
05
Please input item No.
0.00
Pg up Pg dw Enter ↑ ↓
■ PLU Preset-code Key/Display Key Setting (Submode 27)
This programming is used to assign a PLU code to each PLU Preset-code key (SFKC 96), and also used to
assign a display menu table No. to each display key (SFKC 210). You can assign a maximum of 5 different
PLU codes or 5 different display menu table Nos. to one key of the keyboard.
CONDITION Any time outside a sale When you enter 27 and depress the [X] key,
the screen shown below will appear.
OPERATION Mode Lock: SET
27 [X] |Keyboard No.| [ST] |PLU Code or Display Menu Table No.| [KEY] [AT/TL]
Max. 6 digits for PLU Code
1 to 99 for Display Menu Table No.
(Enter 0 to close a key)
1: ECR Keyboard 1
2: ECR Keyboard 2
3: ECR Keyboard 3
4: ECR Keyboard 4
5: ECR Keyboard 5
Depress
the
required
key on
the ECR
Keyboard.
ex.) To assign the PLU code 9 to the required key on the ECR Keyboard 2 and the display menu table No. 2
to the required key on the ECR Keyboard 5.
Mode Lock: SET
Enter 27, depress [X].
2 [ST] 9 [required key of SFKC 96] 5 [ST] 2 [required key of SFKC 210] [AT/TL]
Journal Print
Repeat for other Keys.
P27
PLU KEY
2
PLU
#103 000009
5
DISPLAY
#075 02
0046 16:21TM
Keyboard Phase No.
Location Code (left); refer to REMARK on the next page.
PLU Code assigned to a key (right)
NOTES: 1. When an entry of PLU code or display menu table No. is skipped and a [KEY] is simply
depressed in the above key operation, the preprogrammed PLU code or display menu table No.
of the KEY will be displayed.
2. If “0” is entered as PLU Code or display menu table No. in the above sequence, the KEY will be
closed. Pressing the closed KEY in sale entry will be ignored.
3. The five phases of the keyboard can be shifted by the [MENU] keys in actual sales transaction.
