Chapter 6: Connecting Accessories
38-pin Adapter Cable (E5351A no tip network)
38-pin Adapter Cable (E5351A no tip network)
NOTE: For all Agilent logic analyzers except 16517A, 16518A, 16760A, and
16753/54/55/56A.
The 38-pin adapter cable provides a convenient way to connect two
Agilent Technologies logic analyzer probe cables to a small area of a
target system. The Agilent Technologies E5351A adapter cable does
not have isolation networks, so isolation networks must be provided on
the target system.
NOTE: Agilent Technologies recommends two types of RC networks. They are
described in detail in Probing Solutions for Agilent Logic Analysis Systems.
Go to http://www.tm.agilent.com/classes/ProdSearch to download this
application note. Type in the title, select go, and the document will be listed
under the section Application Notes & Technical Papers.
Logic Analyzer
Pod
Adapter Cable
Shroud
Amp "MICTOR 38"
Connector
Suggested On-board RC Network
10pF
250
ohm
90.9k
ohm
Signal
To
38-pin
Adapter Cable
Ground
Equivalent Load
370
ohm
Signal
Ground
Includes on board RC network and logic analyzer
9pF0.3pF
100k
ohm
AMP "MICTOR 38" Connector Pinout
(Top View)
E
v
e
n
P
o
d
+5VDC
GND DC
CLK
D15
D14
D13
D12
D11
D10
D9
D8
D7
D6
D5
D4
D3
D2
D1
D0
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
O
d
d
P
o
d
CLK
D15
D14
D13
D12
D11
D10
D9
D8
D7
D6
D5
D4
D3
D2
D1
D0
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
Do not connect
Do not connect
Note:
DO NOT connect these
pins to a +5V supply in the
target system!
+5V is supplied from the
logic analyzer to provide power
for analysis probes and demo
boards.
