Definitions: Installation category (overvoltage category) I: Signal level, special equipment or
parts of equipment, telecommunication, electronic etc., with smaller transient
overvoltages than installation (overvoltage category) II.
Installation category (overvoltage category) II: Local level, appliances, portable
equipment etc., with smaller transient overvoltages than installation category III.
Environmental
Conditions
Indoor use only.
Altitude up to 3000 m. (10,000 ft.)
Temperature Instrument - 0 degrees C to 50 degrees C (32 degrees F to 122 degrees F)
Disk Media - 10 degrees C to 40 degrees C (50 degrees F to 104 degrees F
Probes/cables - 0 degrees C to 65 degrees C (32 degrees F to 149 degrees F)
Humidity Relative humidity 8 to 80% at 40 degrees C (104 degrees F)
Power (From host frame.)
EMC This Product meets the requirements of the European
Communities (EC) EMC Directive 89/336/EEC.
Emissions EN55011/CISPR 11 (ISM, Group 1, Class A
equipment)
Immunity EN50082-1
IEC 555-2
IEC 555-3
IEC 801-2 (ESD) 8kV AD
IEC 801-3 (Rad.) 3V/m1
IEC 801-4 (EFT) 1kV
Performance Codes:
1 Pass - Normal operation, no effect.
2 Pass - Temporary degradation, self recoverable.
3 Pass - Temporary degradation, operator
intervention required.
4 Fail - Not recoverable, component damage
.
Performance Code
1
1
1
2
1
1
Safety IEC 348:1978 / HD 401 S1:1981
UL 1244
CSA-C22.2 No. 231 (Series M-89)
Sound Pressure Level N/A
Regulatory Information for Canada
ICES/NMB-001
This ISM device complies with Canadian ICES-001.
Cet appareil ISM est confomre à la norme NMB-001 du Canada.
Regulatory Information for Australia/New Zealand
This ISM device complies with Australian/New Zealand AS/NZS 2064.1
