57
Chapter 3: Installing Logic Analyzer Measurement Modules
16715/16/17A, 16718/19A, 16740/41/42A, 16750/51/52A/B Logic Analyzer (1-card module)
16715/16/17A, 16718/19A, 16740/41/42A, 16750/51/52A/B
Logic Analyzer (1-card module)
Each card shipped stand-alone has the 2 x 10 cable connected in the single-
card module configuration. A single-card module can be installed in any
available slot.
NOTE: Turn off the mainframe power before removing, replacing, or installing
modules following the procedures on page 42.
NOTE: Measurement modules with different model numbers may not be connected
together in multi-card (Master/Expander) modules.
