Chapter 5: Installing Pattern Generator Measurement Modules
16720A Pattern Generator (3-card module)
16720A Pattern Generator (3-card module)
Use three 2 x 10 cables to connect the modules.
NOTE: Turn off the mainframe power before removing, replacing, or installing
modules following the procedures on page 42.
Expander
Master
Expander
2x10 Cable
