Cables and Connectors
Token-Ring Cables
118
Token-Ring Cables
The following table shows the most commonly used Token-Ring cable. Use this
table to verify that you are using compatible Token-Ring cabling throughout your
network. The cable designation is generally stamped on the cable jacket.
NOTE
Make sure that all of your cables have the same Velocity of Propagation (Vp).
Table A-2: Token-Ring Cable Type, Vp, and Impedance
Cable Type VP Impedance
Type 1 (STP) 78 150
Type 3 (UTP) level 3 60 100
Type 3 (UTP) level 4 69 100
Type 3 (UTP) level 5 78 100
