Specifications
126
Specifications
This appendix lists the specifications for the Agilent J3919A and J3972A OC-3
ATMProbes.
Network Compatibility
Agilent J3919A and J3972A
Base
Hardware: 10Base-T/100Base-TX RJ-45 and AUI, Telemetry Interface.
Option 125 1 6-pin DIN connector is used for an Optical Bypass Switch
(optional)
Option 210 1 OC-3 Single Mode Interface
Option 211 1 OC-3 Single Mode Interface and 1 Token-Ring Telemetry
Interface
Option 212 1 OC-3 Multimode Interface
Option 213 1 OC-3 Multimode Interface and 1 Token-Ring Telemetry
Interface
The probe can use either a Fast Ethernet network connection, an optional
Token-Ring network connection, or the SLIP link to communicate with a
management station.
Network Connection
The network connection is made using the standard AUI for 10 MB/s Ethernet.
10Base-T or 100Base-TX half-duplex connections are made using the standard
RJ-45 connector.
The OC-3 ATM circuit connection is made using two fiber SC connectors that
support 155.52 Mbps ATM traffic. Optional transceivers support multimode and
single-mode.
The 6-pin DIN connector is used for an Optical Bypass Switch (optional).
