Local Terminal Configuration
Using a Local Terminal
35
can then view or configure the selected OC-3 ATM port’s
configuration parameters. The following are your OC-3 ATM
port choices:
[3] 3.1/ATM
[4] 3.1/ATM-AL5
[5] 3.1/STS3C-STM1
Port Type Press
2
and select the port type as Monitor-only.
Network Type Press
3
and then select the Network Type as UNI (User
Network Interface) or NNI (Network to Network Interface or
Network to Node Interface).
3. Press
S
to save the configuration changes and return to the probe’s Main
Menu. If you want to cancel your current changes and return to the probe’s
Main Menu, press
0
.
Use the following procedure to view the configure items in the Modify/View
Interface Values menu for the third port on the OC-3 ATM interface. The third
port cannot be configured.
1. Press
3
to access the Modify/View interface values menu item. The
Modify/View Interface Values menu for port 3 is displayed, as shown in
Figure 2-9.
Figure 2-9: Modify/View Interface Values Menu (OC-3 ATM, Port 3)
Modify/View Interface Values Menu - Firmware Rev
Interface Type ATM/AL5
1. Port 3.1/ATM-AL5
2. Port Type Monitor-only
S. Save changes and exit
0. Cancel changes and exit
