Troubleshooting Virtual Router Redundancy Protocol (VRRP) CMM Failover
OmniSwitch Troubleshooting Guide September 2005 page 13-7
-> show vrrp 1 statistics
Virtual Router VRID = 1 on VLAN = 1
State = master
UpTime (1/100th second) = 378890
Become master = 1
Advertisement interval errors = 0
Password errors = 0
Authentication errors = 0
Authentication type errors = 0
IP TTL errors = 0
IP address list errors = 0
Zero priority advertisements sent = 0
Zero priority advertisements received = 0
State The administrative state of the VRRP instance; initialize means that
this VRRP instance is waiting for a startup event, such as a reboot or
when the virtual router is disabled; backup means that this instance is
monitoring the availability and the state of the master router; master
means that this instance is functioning as the master router.
UpTime Time interval (in hundredths of a second) since this virtual router was
last initialized.
Become Master The total number of times this virtual router’s state has transitioned
from backup to master.
Adv. Rcvd The total number of VRRP advertisements received by this instance.
output definitions
VRID The virtual router identifier.
VLAN The VLAN associated with the VRRP instance.
State The administrative state of the VRRP instance; initialize means that
this VRRP instance is waiting for a startup event, such as a reboot or
adding a new virtual router to the configuration; backup means that
this instance is monitoring the availability and the state of the master
router; master means that this instance is functioning as the master
router.
UpTime Time interval (in hundredths of a second) since this virtual router was
last initialized.
Become master The total number of times this virtual router’s state has transitioned
from backup to master.
Advertisements received The total number of VRRP advertisements received by this instance.
Type errors The total number of VRRP packets received with an invalid value in
the VRRP type field.
Advertisement interval errors The total number of VRRP packets received in which the advertisement
interval was different than the one configured for the virtual router.
Password errors The total number of VRRP packets received that did not pass the sim-
ple text password authentication check.
Authentication errors The total number of VRRP packets received with an unknown or
invalid authentication type.
output definitions (continued)
