Troubleshooting Spanning Tree Generic Troubleshooting in Dshell
OmniSwitch Troubleshooting Guide September 2005 page 4-13
MDEFVLAN
This event is received is sent by the Spanning Tree CMM to the NI when the default VLAN of a fixed or
q-tagged port is change (this also applies to logical port). This event is generated on the CMM by VLAN
Manager application.
The parameters are:
• First parameter: Global port identifier.
• Second parameter: new default VLAN.
PORTAGGR
This event is currently unused.
PORTDISG
This event is currently unused.
AGGR_UP
This event is sent by Link Aggregation NI when it detects that a aggregator comes up; It could be either a
static aggregator (OmniChannel) or a dynamic aggregator (802.3ad). This message is generated when the
first port joins the aggregator only.
The parameters are:
• First parameter: The aggregator identifier (logical port ID value between 0 and 31).
• Second parameter: The global port identifier of the physical port that has joined the aggregator.
• Third parameter: The output QID to be used by the Spanning Tree (not significant).
Note. The output QID is no more used by the Spanning Tree since at the time Link aggregation is asking
for the default queue associated to the physical port, Qdriver might not be ready the provide it. However
Link Aggregation keeps providing this parameter even if now this one is not significant.
AGGRDOWN
This event is sent by Link Aggregation NI when it detects that a aggregator goes down; It could be either a
static aggregator (OmniChannel) or a dynamic aggregator (802.3ad). This message is generated when the
last port has leaved the aggregator.
The single parameter is:
• First parameter: The aggregator identifier (logical port ID value between 0 and 31).
