Barco HDX W12 Projector User Manual



12. Alignment
Image 12-162
Dark time adjustment
4. Use the or key to change the dark time until the correct value is reached.
The actual used dark time is indicated next to Actual Dark Time.
12.15.2 Left-right output reference delay
What can be done?
With L/R output reference delay it is possible to apply an adjustable time delay on the stereo emitter signal.
Frame Left
3D Sync
Left
Right
Delay Time
3D Sync
Left
Right
Frame LeftFrame Right
t
Without output reference delay
With output reference delay
Image 12-163
3D Output reference delay
How to set the delay
1. Press Menu to activate the menus and select Alignment 3D Glasses .
214
R5905032 HDX SERIES 02/03/2015
