11. Overview GUI Menus
Installation mode
Adjustment mode - Installation
INSTALLATION
INPUT SLOTS
SOURCE S WITCHI NG
CONFIGURAT ION**
OSD
INTE RNAL PATT ERNS
NO SIGNAL
QUICK ACCESS KEYS
Select with
−
or
/
then <ENTER>
<EXIT> to return
ADJUSTMENT MODE
Select a path from
below
RANDOM ACCESS
INSTALLATION
SERVICE
Source 6
Select with
−
or
/
then <ENTER>
<EXIT> to return
OSD
HIGHLIGHTED ITEM COLOR [YELLOW]
MENU POSITION [DEFAULT]
Select with
−
or
/
<ENTER> to toggle
<EXIT> to return
INPUT SLOTS
Slot Module type [Config]
_____________________________
1. VIDEO [S-VIDEO]
2. NO M ODULE
3. NO M ODULE
4. RGB-YUV [RGB]
5. SDI
6. NO M ODULE
7. RGB-YUV [YUV]
8. HDTV SDI
_____________________________
Select with
−
or
/
<ENTER> to toggle
<EXIT> to return
SEAMLESS SOURCE
SWITCHING
Effect
NO TRANSITION
FADE
WIPE RIGHT
WIPE DOWN
WIPE RIGHT-DOWN
* WIPE WOBBLE
SPLIT VERTICAL OUT
Select with
−
or
/
then <ENTER>
<EXIT> to return
INTERNAL PATTERNS
OUTLINE
HATCH
COLOR B ARS
MULT IBURST
CHECKER BOARD
PURITY
PAGE CHAR
ALPHA-NUMERIC CHARS
Select with
−
or
/
then <ENTER>
<EXIT> to return
NO SIGNAL
COLOR [B LACK]**
SHUTDO WN [OFF]
SHUTDOWN TIME 5 MIN
Select with
−
or
/
then <ENTER>
<EXIT> to return
QUICK ACCESS KEYS
<F1>:
<F2>:
<F3>:
<F4>:
<F5>:
<0>: PIP SOURCE***
CLEAR ALL
Select with
−
or
/
then <ENTER>
<EXIT> to return
* active item
** item not implemented
*** active if P IP status ON
Image 11-10
Installation mode – On screen menu
Adjustment mode - Installation
ADJUSTMENT MODE
RANDOM ACCESS
>INSTALLA TION
SERVICE
< RETURN>
INSTALLATION
INPUT SLOTS
>SOURCE SWITCHING
OSD
INTERNAL PATTERNS
NO SIGNAL
QUICK ACCESS KEYS
< RETURN>
INPUT SLOTS
1. VIDEO [S-VIDEO]
2. NO MODULE
3. NO MODULE
4. RGB-YUV [RGB]
5. SDI
6. NO MODULE
7. RGB-YUV [YUV]
8. HDTV SDI
< RETURN>
SOURCE SWITCHING
NO TRANSITION
FADE
WIPE RIGHT
WIPE DOWN
WIPE RIGHT-DOWN
* WIPE WOBBLE
SPLIT VERTICAL OUT
< RETURN>
* active
OSD
HIGHLIGHTED [GREEN]
MENU POSITION [DEFAULT]
< RETURN>
INTERNAL PATTERNS
OUTLINE
HATCH
COLOR BARS
MULTIBURST
CHECKER BOARD
PURITY
PAGE CHAR
ALPHA-NUMERIC CHARS
< RETURN>
NO SIGNAL
SHUTDOWN [ON]
SHUTDOWN TIME 5 MIN
< RETURN>
QUICK ACCESS KEYS
<F1>
CLEAR ALL
< RETURN>
> selected
> selected
Image 11-11
Installation mode – Menu in graphical display
R5976519 ACSAR 12122002 45
