14. ACSAR Set Ups
14.1 Entering the Service Menu
How to enter the Service menu
1. From the Adjustment mode menu, select item SERVICE. (menu 14-1)
The Service menu appears on-screen and in the graphical display. (menu 14-2)
2. To display the other items of the service mode, select item MORE and press ENTER or press selection wheel to confirm.
Second part of the service mode is displayed. The item MORE, allows to return to part 1 of the service menu. (menu 14-3)
ADJUSTMENT MODE
Select a path from below :
RANDOM ACCESS
INSTALLATION
SERVICE
Select with ↑ or ↓
then <ENTER>
<EXIT> to return
0HQX
SERVICE
IDENTIFICATION
CHANGE PASSWORD
CHANGE LANGUAGE
CHANGE PROJ. ADDRESS
SERIAL COMMUNICATION
MORE....
Select with ↑ or ↓
then <ENTER>
<EXIT> to return
0HQX
SERVICE
BARCO LOGO
PRESET INPUT BALANCE
ADVANCED PROCESSING
DIAGNOSIS
MORE....
Select with ↑ or ↓
then <ENTER>
<EXIT> to return
0HQX
Item PRESET INPUT BALANCE: this item is not active for reason that it belongs to a factory adjusted proce-
dure.
14.2 ACSAR Identification
How to enter the Identification menu
1. From the Service mode menu, select item IDENTIFICATION. (menu 14-4)
The Identification menu appears on-screen and in the graphical display. (menu 14-5)
The identification menu reveals the following info about the ACSAR:
- Address of the ACSAR: adjustable, 0 up to 9 remotely accessible, or up to 255, PC accessible.
- Installed software version.
- Configuration set up: related to D-Cine Premiere which is always Front/Table, not adjustable.
- Baudrate PC: transfer speed for communication with a PC, adjustable.
- Present of a Network module.
- Text: On Screen Display (OSD) enabled (ON) or disabled (OFF).
- Serial number: fabrication number of the unit, useful when calling for technical assistance.
- Run time: total run time since first start up.
2. Press EXIT (RCU) or select item RETURN with selection wheel on ACSAR to return.
SERVICE
IDENTIFICATION
CHANGE PASSWORD
CHANGE LANGUAGE
CHANGE PROJ. ADDRESS
SERIAL COMMUNICATION
MORE....
Select with ↑ or ↓
then <ENTER>
<EXIT> to return
0HQX
BARCO
*ACSAR*
ACSAR. Address: 001
Soft version: 1.0
Config: FRONT/
TABLE
Baudrate PC: 115200
Network module: NO
Text:ON
Serial No: 1234567
Run time: 100h
<EXIT> to return
0HQX
