15. Image Alignment
15.8 Vertical and Horizontal Image Size
How to adjust the image size
1. From the Random Access mode menu, successively select item GEOMETRY and SIZE. (menu 15-26)
The Horizontal Size bar scale appears on-screen and in the graphical display (A numeric value of “0” on the bar scale indicates
no size correction applied).
2. Proceed to the Vertical and Horizontal size adjustment:
The adjustment can be done with the Remote Control or with the selection wheel on the ACSAR.
Adjustment
Numeric buttons
(Max. value between +511 and
-511)
Changing from Vert. to Hor. size
bar scale, press respectively once
cursor key ↑ or →.
•PressENTER to activate the numeric value on the bar scale.
The first digit is active and can be changed.
• Enter new value (only a + or –), using the digit buttons on the
Remote Control. Next digit becomes active.
• Enter new value for next digit, using the digit buttons on the
Remote Control. Next digit becomes active.
• Repeat the same action for the other digits and terminate value
entry with ENTER.
•PressEXIT to return.
Horizontal Size
Cursor keys← and →
•Pressthecursorkeys← or → to display the horizontal size
bar scale.
• Press the cursor keys ← or → until the desired horizontal
size is obtained.
•PressEXIT to return.
With Remote
control
Vertical Size
Cursor keys↑ and ↓
• Press the cursor keys ↑ or ↓ to display the vertical size bar
scale.
• Press the cursor keys ↑ or ↓ until the desired vertical size is
obtained.
•PressEXIT to return.
With selection
wheel
• At start up, horizontal size bar scale is displayed.
• Rotate selection wheel until desired horizontal size correction on screen is obtained.
• Press selection wheel to display vertical size bar scale.
• Rotate selection wheel until desired vertical size correction on screen is obtained.
• Press selection wheel to confirm and return.
• To repeat steps, press selection wheel again. (image 15-8)
RANDOM ACCESS
ADJUSTMENT MODE
FILE SERVICE
IMAGE SETTINGS
PICTURE TUNING
GEOMETRY
PIP
Select with ↑ or ↓
then <ENTER>
<EXIT> to return
0HQX
GEOMETRY
SHIFT
SIZE
SIDE KEYSTONE
BLANKING
ASPECT RATIO [4:3]
OPTIONS
Select with ↑ or ↓
then <ENTER>
<EXIT> to return
0HQX
R5976519 ACSAR 12122002 89
