How to scan using Windows
®
2 - 5
2
Pre-Scanning to crop a portion you want to scan using the scanner glass
(
DCP-7020, MFC-7420 and MFC-7820N Only
)
The
Preview
button is used to preview an image for cropping any unwanted portions from the image. When
you are satisfied with the preview, click the
Scan
button from the scanner window to scan the image.
1
Place the document face down on the scanner glass.
2
Select
Flatbed
in the
Paper source
pull-down box (A).
Note
If your machine has no ADF, you can skip step 2.
3
Select the picture type (B).
4
In the Scan dialog box, click the
Preview
button. The entire document will be scanned into the PC and
will appear in the scanning area.
5
To select the portion you want to scan, click and hold the
left mouse button, then drag the mouse pointer over the
area.
6
If you require advanced settings, click on the tab
Adjust
the quality of the scanned picture
(C). You can select
Brightness
,
Contrast
,
Resolution
and
Picture Type
from the
Advanced Properties
. Click the
OK
button
after you choose your settings.
7
To start scanning your document, click the
Scan
button in the Scan dialog box. This time only the
selected area of the document will appear in the PaperPort
®
9.0SE window (or your software application
window).
A
B
Scanning
area
C
Scanning area
