Chapter 5
Accessing Internal Components
Your computer is designed so you can easily install optional
equipment such as a disk drive, a math coprocessor, or an option
card. Chapters 6 and 7 describe how to install options in your
computer; but first you must open the computer to access the
internal components. Follow the instructions in this chapter
when you need to perform these steps:
0
Remove the computer’s cover
0
Remove the subassembly
Ll
Replace the subassembly
0
Replace the cover.
Be sure to heed all the cautions and warnings so you do not
injure yourself or damage the computer. If you have any
reservations about performing these steps yourself, ask your
Epson dealer for assistance.
Note
You only remove the subassembly to access jumpers or the
math coprocessor socket or to install or remove a disk drive.
You do not need to remove the subassembly to install an
option card or memory modules.
Accessing Internal Components
5-1
