ENWW TCP/IP Configuration 75
subnet-mask A value (in dotted notation) that identifies the network and
host portions of an IP address in received messages. For
example,
subnet-mask 255.255.255.0
stores the subnet mask value 255.255.255.0 on the print
server. The value 0.0.0.0 disables the subnet mask. For
more information see Appendix A
.
default-gw The IP address of a default gateway, in dotted notation.
For example,
default-gw 192.168.40.1
assigns 192.168.40.1 as the IP address of the default
gateway for the print server.
Note: If the HP Jetdirect print server is configured by DHCP
and you manually change the subnet mask or the default
gateway address, you should manually change the print
server’s IP address. This will release the DHCP-assigned
address back to the DHCP IP address pool.
Config Server (Read-only parameter) The IP address of the server (such
as a BOOTP or DHCP server) that last configured the IP
address on the HP Jetdirect print server.
TFTP Server (Read-only parameter) The IP address of the TFTP server
that provided TFTP parameters to the HP Jetdirect print
server.
TFTP Filename (Read-only parameter) The path and TFTP filename on the
TFTP server. For example,
hpnp/printer1.cfg
domain-name The domain name for the device. For example,
domain-name support.hp.com
assigns support.hp.com as the domain name.
The domain name does not include the host name; it is not
the Fully Qualified Domain Name (such as
printer1.support.hp.com).
pri-dns-svr IP address of the primary DNS (Domain Name System)
server.
sec-dns-svr IP address of a secondary DNS server to use if the primary
DNS server is unavailable.
pri-wins-svr The IP address of the primary Windows Internet Name
Service (WINS) server, in dotted notation.
sec-wins-svr The IP address of the secondary Windows Internet Name
Service (WINS) server, in dotted notation.
Table 3.4 Telnet Commands and Parameters (3 of 13)
