Chapter 4
Advanced Configuration
22
10/100 4-Port VPN Router
Network Service Detection
Enable Network Service Detection Network Service
Detection helps manage your connection and can report
when your connection experiences problems. To use this
service, select this option.
Retry Count Enter the number of times the Router will
try to reconnect if the connection fails.
Retry Timeout Enter the number of times the Router will
try to make a connection to your ISP before it times out.
When Fail Should the connection be lost, set the Router
to perform one of the following actions, Remove the
Connection or Generate the Error Condition in the
System Log.
Remove the Connection • Failover will occur; the
backup will be used. When the primary WAN port’s
connectivity is restored, the backup WAN port will
return to standby mode.
Generate the Error Condition in the System •
Log Failover will not occur; only an error condition
will be logged.
Network Service Detection can test a WAN port’s network
connectivity by pinging the Default Gateway or a specific
IP address.
WAN1/2
Default Gateway Select this option to ping the Default
Gateway.
ISP Host Select this option to ping the ISP Host. Then
enter the IP address.
Remote Host Select this option to ping the Remote Host.
Then enter the IP address.
DNS Lookup Host Select this option to ping the DNS
Lookup Host. Then enter the IP address.
Click Save Settings to save your changes, or click Cancel
Changes to undo them.
Load Balance
System Management > Dual-WAN > Load Balance
Network Service Detection
Enable Network Service Detection Network Service
Detection helps manage your connection and can report
when your connection experiences problems. To use this
service, select this option.
Retry Count Enter the number of times the Router will
try to reconnect if the connection fails.
Retry Timeout Enter the number of times the Router will
try to make a connection to your ISP before it times out.
When Fail Should the connection not be reestablished,
set the Router to perform one of the following actions,
Remove the Connection or Generate the Error
Condition in the System Log.
Network Service Detection can test this connection by
pinging the Default Gateway or a specific IP address.
WAN1/2
Default Gateway Select this option to ping the Default
Gateway.
ISP Host Select this option to ping the ISP Host. Then
enter the IP address.
Remote Host Select this option to ping the Remote Host.
Then enter the IP address.
