Chapter 4
Advanced Configuration
23
10/100 4-Port VPN Router
DNS Lookup Host Select this option to ping the DNS
Lookup Host. Then enter the IP address.
Bandwidth
WAN1/2
Upstream Enter the maximum upstream bandwidth
provided by your ISP. The default is 512 kbit/sec.
Downstream Enter the maximum downstream
bandwidth provided by your ISP. The default is
512 kbit/sec.
Protocol Binding
Service Select the Service you want.
If the Service you need is not listed in the menu, click
Service Management to add the new service. The Service
Management screen appears.
Service Management
Service Name Enter a name. For IP Binding only, select
All.
Protocol Select the protocol it uses.
Port Range Enter its range.
Click Add to List. Click Save Settings to save your changes,
or click Cancel Changes to undo them. Click Exit to return
to the Dual-WAN screen.
If you want to modify a service you have created, select it
and click Update this service. Make changes. Click Save
Settings to save your changes, or click Cancel Changes to
undo them. Click Exit to return to the Dual-WAN screen.
If you want to delete a service you have created, select it
and click Delete selected service. Click Save Settings
to save your changes, or click Cancel Changes to undo
them. Click Exit to return to the Dual-WAN screen.
Source IP Enter the source IP address or range. If you
need Service Binding only, then you can keep the default,
which is 0.
Destination IP Enter the destination IP address or range.
If you need Service Binding only, then you can keep the
default, which is 0.
Interface Select the appropriate WAN interface, WAN1
or WAN2.
Enable Select Enable to use this Protocol Binding rule.
Click Add to List, and configure as many rules as you
would like, up to a maximum of 100. To delete a rule, select
it and click Delete selected application.
Click Save Settings to save your changes, or click Cancel
Changes to undo them.
System Management > Bandwidth
Management
Quality of Service (QoS) features let you control how
the Router manages network traffic. With Bandwidth
Management (Layer 3), the Router can provide better
service to selected types of network traffic. There are two
types of functionality available, and only one type can
work at one time. Rate Control functionality is for minimum
(guaranteed) bandwidth and maximum bandwidth by
service or IP address, while Priority functionality is for
services. Both types can control inbound or outbound
traffic.
System Management > Bandwidth Management > Rate Control
