Chapter 4
Advanced Configuration
42
10/100 4-Port VPN Router
IP + E-mail Addr.(USER FQDN) Authentication
Local Security Gateway Type > IP + E-mail Addr.(USER FQDN)
Authentication
E-mail address Enter the e-mail address for
authentication.
IP address The WAN (or Internet) IP address of the Router
automatically appears.
Dynamic IP + Domain Name(FQDN) Authentication
The Local Security Gateway will be a dynamic IP address,
so you do not need to enter the IP address. When the
Remote Security Gateway requests to create a tunnel with
the Router, the Router will work as a responder.
The domain name must match the Remote Security
Gateway of the remote VPN device and can only be used
for one tunnel connection.
Local Security Gateway Type > Dynamic IP + Domain Name(FQDN)
Authentication
Domain Name Enter the domain name for authentication.
(Once used, you cannot use it again to create a new tunnel
connection.)
Dynamic IP + E-mail Addr.(USER FQDN) Authentication
The Local Security Gateway will be a dynamic IP address,
so you do not need to enter the IP address. When the
Remote Security Gateway requests to create a tunnel with
the Router, the Router will work as a responder.
Local Security Gateway Type > Dynamic IP + E-mail Addr.(USER FQDN)
Authentication
E-mail address Enter the e-mail address for
authentication.
Local Security Group Type
Select the local LAN user(s) behind the Router that can
use this VPN tunnel. Select the type you want to use: IP,
Subnet, or IP Range. Follow the instructions for the type
you want to use.
NOTE: The Local Security Group Type you select
should match the Remote Security Group Type
selected on the VPN device at the other end of
the tunnel.
After you have selected the Local Security Group Type, the
settings available on this screen may change, depending
on which selection you have made.
IP
Only the computer with a specific IP address will be able
to access the tunnel.
Local Security Group Type > IP
IP address Enter the appropriate IP address. The default
IP is 192.168.1.0.
Subnet
The default is Subnet. All computers on the local subnet
will be able to access the tunnel.
Local Security Group Type > Subnet
IP address Enter the IP address. The default is
192.168.1.0.
Subnet Mask Enter the subnet mask. The default is
255.255.255.0.
IP Range
Specify a range of IP addresses within a subnet that will be
able to access the tunnel.
Local Security Group Type > IP Range
IP range Enter the range of IP addresses. The default is
192.168.1.0~254.
Remote Client Setup
Remote Client
Select the type you want to use: IP Only, IP + Domain
Name(FQDN) Authentication, IP + E-mail Addr.(USER
FQDN) Authentication, Dynamic IP + Domain
Name(FQDN) Authentication, or Dynamic IP + E-
mail Addr.(USER FQDN) Authentication. Follow the
instructions for the type you want to use.
