63
Gateway-to-Gateway VPN Tunnel
10/100 4-Port VPN Router
Appendix C
In the 11. Preshared Key field, enter a string for this key, for
example, 13572468.
RVL200 IPSec Setup Settings
If you need more detailed settings, click 12. Advanced
Settings. Otherwise, click Save Settings and proceed
to the next section, “Configuration of the RV042.”
Configuration of the RV042
Follow similar instructions for the RV042.
Launch the web browser for a networked computer, 1.
designated PC 2.
Access the web-based utility of the RV042. (Refer to 2.
“Chapter 4: Advanced Configuration” for details.)
Click the3. VPN tab.
Click the 4. Gateway to Gateway tab.
Enter a name in the 5. Tunnel Name field.
Select the appropriate Interface, 6. WAN1 or WAN2.
Select 7. Enable.
For the Local Security Gateway Type, select 8. IP Only.
The WAN IP address (B.B.B.B) of the RV042 will be
automatically detected.
For the Local Security Group Type, select Subnet. Enter
the RV042’s local network settings in the IP Address and
Subnet Mask fields.
RV042 VPN Settings
For the Remote Security Gateway Type, select 9. IP Only.
Enter the RVL200’s WAN IP address in the IP Address
field.
For the Remote Security Group Type, select 10. Subnet.
Enter the RVL200’s local network settings in the IP
Address and Subnet Mask fields.
In the IPSec Setup section, select the appropriate 11.
encryption, authentication, and other key management
settings. (These should match the settings of the
RVL200.)
In the 12. Preshared Key field, enter a string for this key, for
example, 13572468.
RV042 IPSec Setup Settings
If you need more detailed settings, click 13. Advanced.
Otherwise, click Save Settings.
Configuration of PC 1 and PC 2
Verify that PC 1 and PC 2 can ping each other (refer to
Windows Help for more information). If they can ping
each other, then the VPN tunnel is configured correctly.
