Cajun P332MF User’s Guide 1
Chapter 1
Overview
The Cajun™ P330 family of stackable Ethernet workgroup switches includes a
range of modules with 10/100/1000 Mbps ports and a Layer 3 capability/ATM
Expansion sub-module. The Cajun P332MF switch has 12x100BaseFX MT-RJ ports
and an Expansion sub-module slot. The optional expansion sub-modules provide
additional Ethernet, Fast Ethernet, and Gigabit Ethernet connectivity.
A Cajun P330 stack can contain up to 10 switches and up to 3 backup power supply
units. The stacked switches are connected using the Cajun X330STK stacking sub-
modules which plug into a slot in the back of the Cajun P330. They are connected
using the X330SC or X330LC cable (if the stack is split between 2 racks). The Cajun
X330RC cable connects the top and bottom switches in the stack and provides
redundancy and hot-swappability in the same way that modules can be swapped in
a modular switching chassis.
The Cajun P330 is fully compliant with IEEE standards for VLAN Tagging, Gigabit
Ethernet, Spanning Tree and Flow Control. This full standards-compliance,
combined with auto-negotiation for 10/100/1000 Mbps and half/full duplex
facilitates the expansion of your network to match your company's growing needs.
Cajun P330 Family Features
• You can connect up to 10 Cajun P330 switches in a stack. Moreover, this stack
can be either in one rack or split over several racks using the X330LC Long
Cable, according to your requirements.
• Cajun X330STK - this stacking sub-module is used to connect Cajun P330
switches in a stack, via the Octaplane.
• Cajun P330 BUPS - this back-up power supply module supports up to four
Cajun P330 switches.
• One RJ-45/RS232 front panel console connector for both terminal and modem
(future) sessions.
• Two fan units in every switch, with operation sensors.
• One virtual IP address for managing the whole stack, the P330 stack is managed
as a single entity.
• Hot-swapping of one switch at a time - by activation of the redundant cable:
— Does not disrupt the operation of other Cajun P330 switches.
— Does not change stack configuration.
— Does not require network downtime.
• Connection through Telnet from the front panel ports of
any switch, with:
— multiple levels of password protection
— login and inactivity timeouts
