Q1860-90918 Chapter 3 Printer operation 61
Table 24 shows the sequence of keystrokes that is used to change the page count from a value
of 000000 to a value of 0010480.
Maintenance page count, interval, and reset
The maintenance page count allows for input of the number of pages since the last maintenance
kit was installed. This corresponds to “pages since last maintenance” on the configuration page.
Editing this number is similar to editing the
PAGES item (see table 24).
If the printer has not reached the first maintenance interval (for example, 150,000 pages), then
set the maintenance count equal to the page count.
The maintenance page count should be reset only after a maintenance kit has been installed.
This resets the maintenance counter so that the message
PERFORM PRINTER MAINTENANCE
appears after another 150,000 pages have been printed (default).
Hold down the [-ITEM] and [-VALUE] keys.
Turn the printer on.
Wait for RESET MAINT COUNT to appear and then release both keys.
MAINTENANCE INTERVAL in the service mode menu sets the page count interval at which the
next service is due for the printer. This is set initially at the factory to 150,000 pages. (For
example, the message appears at 150,000 pages. If the printer maintenance kit is installed at,
and the counter is set to, 150,114 pages, then the message appears 150,000 pages later, at
300,114 pages.) Editing this number is similar to editing the
PAGES item (see table 24).
Serial number
If a formatter is replaced, then the serial number must be recorded. Editing this number is similar
to editing the
PAGES item (see table 24).
Table 24. Using control panel keys to change page count (an example)
Key Press Display Description
SERVICE MODE
[Menu+]
SERVICE MENU
Open the SERVICE MENU.
[Item+]
PAGES=0000000 *
Advance to the first item in the SERVICE MENU.
[Select]
PAGES=0000000 *
Advance the cursor one digit to the right.
[Select] PAGES=0000000 * Advance the cursor one digit to the right.
[Value+]
PAGES=0010000 *
Increase the value of the third digit by one.
[Select]
PAGES=0010000 *
Enter the change to the third digit and advance the cursor
one digit to the right.
[Select]
PAGES=0010000 *
Advance the cursor one digit to the right.
[Value+]
(4 presses)
PAGES=0010400 *
Increase the value of the fifth digit by four.
[Select]
PAGES=0010400 *
Enter the change to the fifth digit and advance the cursor
one digit to the right.
[-Value]
(2 presses)
PAGES=0010480 *
Decrease the value of the sixth digit by two.
[Select]
(2 presses)
PAGES=0010480 *
Enter the change to the sixth digit and advance the cursor
one digit to the right, causing the cursor to wrap around to
the first digit.
[Go] Exit the service menu.
