3. Installation
Lens Partnumber
CLD (2.4-4.3:1)
R9849890
QCLD (1.1-1.3:1)
R9849850
QCLD (0.85:1)
R9849860
See the Maintenance appendix for more information about lens cleaning.
3.2.4 Lens Formulas
Formulas
Lenses
Metric Formulas (meter) Inch formulas (inch)
QCLD (0.85:1) PD = 0.86 X SW + 0.06 PD = 0.86 X SW + 2.36
QCLD (1.1-1.3:1) PD
min
= 1.1 X SW + 0.05
PD
max
= 1.3 X SW + 0.06
PD
min
= 1.1 X SW + 1.97
PD
max
= 1.3 X SW + 2.36
CLD (1.2-1.6:1) PD
min
= 1.19 X SW + 0.02
PD
max
=1.63XSW+0.02
PD
min
=1.19XSW+0.79
PD
max
=1.63XSW+0.79
CLD (1.6-2.4:1) PD
min
= 1.58 X SW + 0.00
PD
max
=2.39XSW-0.02
PD
min
=1.58XSW+0.00
PD
max
=2.39XSW-0.79
CLD (2.4-4.3:1) PD
min
= 2.38 X SW - 0.03
PD
max
=4.32XSW-0.01
PD
min
=2.38XSW-1.18
PD
max
=4.32XSW-0.39
3.3 Projector conguration
The different congurations
Depending on the installation the projector can be mounted in different ways, the 4 different congurations are:
1. Rear/Ceiling
2. Rear/Table
3. Front/Ceiling
4. Front/Table
