3. Installation
CAUTION: Never place the projector on either side !
Floor
Floor
Image 3-9
3.5 Connections
3.5.1 Power connection
AC power (mains) cord connection
Use the supplied power cord to connect your projector to the wall outlet.
Plug the female power connector into the male connector at the fr
ont of the projector.
The power input is auto-ranging from 90 to 240 VAC.
Fuses
For continued protection against fire hazard :
• refer replacement to qualified service personnel
• ask to replace with the same type of fuse.
3.5.2 Input Source connections
Overview
• Input section
• Input facilities
• 5-Cable input
• Composite Video Input
• S-Video input
• Digital Visual Interface (DVI) input
• Computer input
• Serial Digital Interface (Optional)
• Audio input/Output (Optional)
• Communications Connections
16
R59770134 ID LR-6 27/05/2011
