3-9
Confidential
5
TONER LED PCB ASSY / REGISTRATION FRONT SENSOR PCB ASSY / REGISTRATION REAR SENSOR PCB ASSY
6
PANEL PCB ASSY / TONER SENSOR PCB UNIT ASSY / NEW TONER SENSOR HARNESS ASSY
Registration rear sensor PCB ASSY
Registration front sensor PCB ASSY
Toner LED PCB ASSY
<Front side>
<Right side>
Toner sensor PCB unit ASSY
New toner sensor
harness ASSY
Panel PCB ASSY
<Left side>
<Front side>
