122 PMCS Interface Toolkit
EPM 7300 Meter
The EPM 7300 Tabular Data Screen wizard has several special features. You can use
the Setup screen to change the meter configuration. Values displayed in white boxes
are changeable. Some are changed by clicking on the displayed value, while others
are changed by clicking on the associated scroll button. The Download and Refresh
buttons on the setup screen upload and download all of the setpoints from the device.
To change setpoints at the device, first press the refresh button to upload current
setpoint values from the device (otherwise the defaults are shown and used for
download). Modify setpoints as desired, then press the download button to send all
setpoints to the unit.
The EPM 7300 Tabular Data Screen’s command buttons are described below:
Tab Button Function
Metering Reset Energy Resets all Energy Integrators in the meter.
MIN/MAX Demand Digital Input Labels The user can enter descriptive text (up to 20 characters) for each digital
input. These labels are retentive.
Force ON For each digital output, this button will force the output to the ON state.
Force OFF For each digital output, this button will force the output to the OFF state.
Reset Sliding
Demand
Resets all Sliding Demand Values in the device.
Reset Min/Max Resets all Min/Max values in the device.
Table 21. EPM 7300 Tabular data screen commands.
