144
Changing Your Workstation’s Hardware Configuration
Removing Cache Boards
Removing Cache Boards
Follow these steps to remove the cache boards from the workstation.
1 Locate the cache boards on the CPU board, as shown in Figure 48.
Figure 48 Cache Boards Location
2 To remove a cache board, push the ejector tabs on each side of the board. Lift
the cache board up and out of the connector and place it on a static free sur-
face.
Cache Board Connectors
