Chapter 2 System Overview
2.3.2 CHASSIS LAYOUT
This section describes the internal layout of the chassis. For detailed information on servicing the
chassis refer to the multimedia training and/or the Service Reference Guide for these systems.
Figure 2-4 shows the layout for the Compaq D315 or hp d325 personal computers.
Front
Back
Power Supply
Chassis Fan
AGP Slot
NIC Card [1] in PCI Slot 1
PCI Slot 2
PCI Slot 3
Externally Accessible
Drive Bays
Processor/Heat Sink/Fan
Assembly
Internal
Drive Bays
Front Panel
Audio/USB
board
NOTES/LEGEND:
[1] If present.
D315 model (board mounted horizontally)
d325 model
(
board mounted veriticall
y)
Figure 2-4. Chassis Layout, Left Side View
Compaq D315 and hp d325 Personal Computers
Featuring the AMD Athlon XP Processor
Second Edition – March 2003
2-6
