4-7
Configuring the Switch From the Console
Configurable Features
Configuring the Switch From
the Console
(Optional) How To Configure IPX for Management from a Remote IPX
Network. To enable management from a remote IPX network, you must
configure the gateway encapsulation type.
1. From the Configuration screen, select IPX Service to display the above
screen.
2. Press [E] (for E
dit).
3. If the IPX Enabled parameter is not already set to “Yes” (the factory
default), then select this parameter and press the Space bar to select Yes.
4. Select the Gateway Encap field and use the Space bar to select the appro-
priate gateway encapsulation for the gateway device.
5. Press [Enter], then [S] (for S
ave).
6. Return to the Main Menu and reboot the switch.
YUMAMOD.BK : 4_ymcnfg.fm5 Page 7 Thursday, February 20, 1997 12:54 PM
