Diagnostic Information 2-96
4059-XXX
Print Quality - Background
Service Tip: Some background problems can be caused by rough
papers or non-Lexmark toner cartridges. If the rough paper mode is
on, turn it off and run the print test.
Some slick or coated papers may also cause background. Some
problems occur with printers that run a large amount of graphics in a
humid environment. The customer may try to improve the print
quality by increasing the transfer setting.
7 Lines spaced 49.74 mm
(1.958 inch) apart
Replace the FRUs in the following
order:
redrive assembly
fuser assembly
8 Lines spaced 51.02 mm
(2.009 inch) apart
Replace the transfer roll.
9 Lines spaced 52.23 mm
(2.056 inch) apart
Replace the redrive assembly.
10 Lines spaced 76.53 mm
(3.013 inch) apart
Replace the FRUs in the following
order:
alignment assembly
main drive gearbox assembly
11 Lines spaced 95.66 mm
(3.766 inch) apart
Replace the FRUs in the following
order:
toner cartridge
main drive gearbox assembly
12 Lines spaced 99.49 mm
(3.917 inch) apart
Replace the redrive assembly.
13 Lines spaced 114.79 mm
(4.519 inch) apart
Replace the alignment assembly.
FRU Action
