Parts Catalog 7-5
4059-XXX
Asm-
Index
Part
Number
Units Description
1-12 99A0001 1 Operator Panel Assembly
1-13 99A0009 1 Cover, Left Side
1250/1255/1620/1650/2420/1855/1625
1-13 99A0010 1 Cover, Left Side 2450/2455/3455
NS 5 Screw, Left Side Cvr Mtg PP 99A0263
1-14 99A0017 1 Door, Left Panel 1650/1855/2420
1-14 99A0019 1 Door, Left Panel 1250/1255/1620/1625
1-14 99A0018 1 Door, Left Panel 2450/2455/3455
1-15 99A0296 1 Switch, Cover Open w/Operator Panel Cable
Assembly
1-16 99A0003 1 Latch, Upper Cover
1-17 99A0013 1 Cover, Laser Assembly
NS 6 Screw, Laser Cover PP 99A0263
NS 99A0552 1 Cover Assembly, Redrive Cap
NS 99A0573 2 Nut, Front Spacer Mounting 2450/2455/3455
1-18 99A0550 1 Shield, ESD Cover Open
1-19 99A0031 1 Bracket, Cover Open Switch
1-20 99A0036 1 Spring, Cover Open Switch
1-21 2 Screws, Contact Mounting PP 99A0263
1-22 99A0814 1 Cable, Smart Cartridge 3455
1-23 99A0816 1 Contact, Smart Cartridge Ground 3455
1-24 99A0815 2 Contact, Smart Cartridge 3455
1-25 99A0817 1 Cover, Smart Cartridge Contact 3455
1-26 99A0834 1 Plunger, Overstress Smart Cartridge 3455
NS 99A0577 1 Cable Tie
