Parts Catalog 7-49
4059-XXX
Asm-
Index
Part
Number
Units Description
15-1 99A0287 1 Pick Arm Assembly
15-2 3 Screw, Auto Comp Mounting PP 99A0263
15-3 99A0070 2 Roll Assembly, Pick
NS 99A0438 2 Bearing, Drive Roll
15-4 99A0448 1 Arm, Paper Out 250
15-5 99A0266 1 Base, 250 Option
15-6 99A0026 1 Tray Bias Arm Assembly
15-7 99A0419 1 Spring, Tray Bias
15-8 99A0058 4 Pad, Machine Mounting
15-9 99A0288 1 Sensor, Option Pass Thru
15-10 99A0272 1 Shaft, 250 Drive
15-11 99A0275 1 Spring, Power Takeoff
15-12 99A0282 1 Cable, 250 Tray Option
15-13 99A0451 1 Roller, Skewed Backup
15-13B 99A0450 1 Retainer, Roller
15-14 99A0276 1 Roll Assembly, Drive 500 Dual
15-15 2 Screw, Wear Plate Mounting PP 99A0263
15-16 99A0277 1 Wear Plate, Pass Thru 250 Tray
NS 99A0278 1 Bellcrank, Roller Release
15-17 99A0280 1 Bearing, Drive Shaft Low
15-18 99A0274 1 Gear, Feed Roll
15-19 99A0273 1 Gear, Bevel
15-20 99A0279 1 Bearing, Drive Shaft
15-21 99A0445 1 Stud Assembly, 250 Frame
15-22 99A0281 1 Cable, 250 Auto Connect Option
15-23 1 Screw, Switch Activate Spring Mounting
PP 99A0263
15-24 3 Screw, Option Board Mounting
PP 99A0263
15-25 99A0284 1 Board, Option Tray
1250/1620/1650/2420/2450
15-25 99A0397 1 Board, Option Tray
1255/1625/1855/2455/3455
15-25A 99A0627 1 Jumper, 2-pin
15-26 99A0063 1 Spring, Switch Activate
