Chapter 6 Command line interface 103
Using the Passport 8683POS Module
.
Table 36 Information fields for output of the show ports info pos all
command
Field Description
PORT NUM Port number.
FRAMING MODE Indicates whether the framing mode is either:
• sonet
• sdh
CLOCK SOURCE Indicates whether the clock source is either:
• line
• internal
SECTION TRACE Indicates the integer that the section trace flag (j0) is set to.
SIGNAL LABEL Operational value of Path Signal Label (C2). The signal
label value is reset when the scramble value is changed.
SCRAMBLE Enables or disables the scrambling option.
ADMIN STATUS Sets the port to one of the following states:
• up
• down
• testing
BRIDGE ADMIN This parameter indicates bridged traffic within PPP.
IP ADMIN This parameter indicates the IP traffic (link) within PPP.
IPX ADMIN This parameter indicates the IPX traffic (link) within PPP.
MAGIC NUMBER If set to enable, selects a random number (“magic
number”) used in loopback detection. enable detects
loopback; disable does not detect loopback.
STPMODE Spanning Tree Protocol mode - This parameter enables
BPDUs to be received or transmitted with BPDU specific
encapsulation. When disabled, encapsulated within
Ethernet frames.
PPP LQSTATUS Sets the link quality reporting interval.
SPEED Displays the current operating speed of the port. It can be
either 155 or 622 Mb/s depending on the type of interface
installed.
