Chapter 4 Managing the Passport 8683POS Module 49
Using the Passport 8683POS Module
The ports on the graphical image are color-coded to provide at-a-glance port
status. Table 4 shows the status assigned to each color code.
Additionally, many Device Manager windows and dialog boxes contain buttons.
Table 5 describes the function of these buttons.
Table 4 Passport Device Manager port color codes
Field Description
Green Port is operating.
Red Port has been manually disabled.
Orange Port has no link.
Light blue Port is in standby mode.
Dark blue Port is being tested.
Gray Port is unmanageable.
Table 5 Passport Device Manager buttons
Field Description
Apply Applies the changes you entered to fields in a window or dialog box.
Refresh Refreshes the information in the window. Each time you click Refresh,
new information is polled from the switch and is displayed.
Close Closes the window or dialog box and disregards any changes you
made to fields.
Help Does not function with the Passport 8683POS Module.
Insert Inserts or creates new information.
Resize Columns Resizes columns on the screen.
Note: You must always click Apply at the bottom of the tab to
implement any changes you make.
