76 Chapter 4 Managing the Passport 8683POS Module
209564-A
Table 19 Test tab items
6 Click Ext. Loopback to test the external loopback or click Int. Loopback to
test the internal loopback.
A dialog box displays the test results.
7 Click Stop to cease testing.
8 Click Close.
9 Click the Interface tab.
10 In the AdminStatus field, click up.
11 Click Apply.
The test statistics are available only when the test has finished, unlike Ethernet
ports where the test statistics can be viewed during testing.
Item Description
Result Result of the test.
Code Code used for test.
PassCount Number of events which passed the test.
FailCount Number of events which failed the test.
Note: To run the external loopback test, you need a loopback cable on
that port.
