9-29
n Assembly of Main Unit
DU PCB ASSY
Main PCB Ass’y
Insert it before setting
the Main Board.
Audio FPC Ass’y
Apply the lubricant (sub material) on the
HDD Connector for about 1 second.
(Note for spraying around when applying.)
Audio FPC Ass’y
Avoid running the Cable
over the Connector.
Insert the Bastaraid between
the LAN/MODEM Connectors.
0 1mm
Safety critical componentInsert
and then lock.
Audio FPC
Tape
Screw
Screw
Screw
Screw
Screw
Screw
Screw
Screw
Screw
Screw
Thermal Sheet
Wireless Module
Lengthwise
Fold back
Stiffening Plate Side
Center of module
to the notch
Insert and then lock
Details of the LAN/MODEM
Insert and then lock.
Connect
Round to make the brown side
outside and insert the notch.
Attach it on the
center of the
FPC.
3mm
Important Parts
for Safety
SD PCB Ass’y
DIMM HOLDER Ass’y
Ensure that the knob is fit to SW when setting.
Insert the FPC
Insert the hook
Fit it to the corner of the SD board
HDD Connector Guide
Screw
Screw
Screw
Screw
Screw
Screw
Screw
Thermal Rubber
DIMM Holder
RF SW Knob
